Drive Axle Forklift

Drive Axle for Forklift - A forklift drive axle is a piece of equipment which is elastically affixed to a vehicle framework utilizing a lift mast. The lift mast is connected to the drive axle and is capable of being inclined around the drive axle's axial centerline. This is accomplished by at least one tilting cylinder. Forward bearing components combined with back bearing elements of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing parts. The lift mast could also be inclined relative to the drive axle. The tilting cylinder is affixed to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.

Model H40, H45 and H35 forklifts, which are produced by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle framework itself. The drive axle is elastically attached to the framework of the forklift using numerous different bearings. The drive axle has tubular axle body together with extension arms connected to it and extend rearwards. This particular kind of drive axle is elastically attached to the vehicle framework by back bearing elements on the extension arms along with frontward bearing tools located on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing device in its respective pair.

The braking and drive torques of the drive axle are sustained through the rear bearing elements on the frame by the extension arms. The lift mast and the load generate the forces which are transmitted into the street or floor by the framework of the vehicle through the drive axle's anterior bearing components. It is important to make sure the elements of the drive axle are configured in a firm enough method in order to maintain immovability of the forklift truck. The bearing elements can reduce slight road surface irregularities or bumps all through travel to a limited extent and provide a bit smoother function.
